This o-ring is ideal to get a good and water-proof sealing in our cable glands PRPRE and our plugs PRTH and PRT. It can be used in the majority of industrial applications including water, oil, petrol and most chemicals. Our o-ring is available for metric thread and for PG thread.

Drawing PDF:
UL94:
IP:
RoHS:
Measures expressed in: Millimeters

PRP
PRP

Reference
Thread
Outside diameter (OD)
Inside diameter (ID)
D



More
Info.
03400100000 · 7,00 3,00 2,00
01500800269 M12 12,00 9,00 1,50
03400100001 M14 15,00 12,00 1,50
01500800270 M16 17,00 14,00 1,50
03400100002 M18 19,00 16,00 1,50
01500800271 M20 21,00 18,00 1,50
03400100003 M22 23,00 20,00 1,50
01500800272 M25 26,00 23,00 1,50
01500800273 M32 32,00 28,00 2,00
01500800274 M40 40,00 36,00 2,00
01500800275 M50 50,00 46,00 2,00
01500800276 M63 61,00 57,00 2,00
01500800277 PG7 13,00 10,00 1,50
01500800278 PG9 16,00 13,00 1,50
01500800279 PG11 19,00 16,00 1,50
01500800280 PG13 21,00 18,00 1,50
01500800281 PG16 23,00 20,00 1,50
01500800282 PG21 30,00 26,00 2,00
01500800283 PG29 38,00 34,00 2,00
01500800284 PG36 48,00 44,00 2,00
01500800285 PG42 54,00 50,00 2,00
01500800286 PG48 59,00 55,00 2,00

If you are interested in our family PRP, you may be interested in these families as well:

This part is a 100% waterproof cable gland (IP68 - 5 bar). Its design gives the possibility to fit several cable diameters with secure protection and fastening. It can be supplied with a plug protector, and an O-ring PRP for watertightness and an adapter joint PRTI for several cables. Also, you can find the corresponding lock nut: PRTUE. Please contact us for more information.   Polystyrene threaded plug suitable for Metric and PG threads. Its slotted head enables it to be (un)screwed with a screw driver. If you are interested in an O-ring for sealing tightness, please visit our group PRP.   Nickel brass threaded plug suitable for Metric and PG threads. Its slotted head enables it to be (un)screwed with a screw driver. If you are interested in an O-ring for sealing tightness, please visit our group PRP.   Threaded plugs that effectively protect internal threads in hydraulic and pneumatic equipment during coating processes or transport. We recommend our plugs manufactured in PA6 for high temperature applications (up to 80°C). Some references can be supplied with an O-ring upon request, please contact us.   Threaded plugs that effectively protect internal threads in hydraulic and pneumatic equipment during coating processes or transport.   Threaded plugs that effectively protect internal threads in hydraulic and pneumatic equipment during coating processes or transport. We recommend our plugs manufactured in PA6 for high temperature applications (up to 80°C). Some references can be supplied with an O-ring upon request, please contact us.   Threaded plugs that effectively protect internal threads in hydraulic and pneumatic equipment during coating processes or transport. They resist high temperature applications (up to 80°C). Some references can be supplied with an O-ring upon request, please contact us.
