Our MDC branch sleeves are made of soft TPE in a “Y” configuration to create derivations between tube sections.

These sleeves, UV-resistant, are pressure-mounted on tube ends and, thanks to their internal teeth, adhere perfectly to the outer profile. Wall mounting holes have a Ø 4 mm diameter. They can be used even between tubes of different sizes.

· Material: TPE
· Color: grey or black
· Operating temperature: -40 °C / +120 °C (with tips up to +150 °C)
· IP protection: IP66 according to EN 60529

Certifications: GOST, UKCA.


Drawing PDF:
UL94:
IP:   66
RoHS:
Measures expressed in: Millimeters
Video:

MDC
MDC

Reference
For tube (D1)
For tube (D2)
B1
B2
L
H



More
Info.
02009000019 10,00 10,00 17,50 17,50 36,50 54,50
02009000020 18,50 18,50 26,50 26,50 54,50 81,00
02009000021 21,20 15,80 29,50 25,00 52,00 75,00
02009000022 21,20 21,20 29,50 29,50 62,50 82,50
02009000023 28,50 15,80 36,50 25,00 52,00 75,00
02009000024 28,50 21,20 36,50 29,50 61,50 81,50
02009000025 34,50 28,50 42,50 36,50 79,00 86,00
02009000026 42,50 34,50 52,50 42,50 89,00 98,50
02009000027 54,50 42,50 65,00 52,50 109,50 116,00

If you are interested in our family MDC, you may be interested in these families as well:

<p>Our <b>corrugated polypropylene tube MPP</b> is a flexible flame-resistant component designed for technical applications in industrial and outdoor environments. It offers excellent UV resistance and a service life of at least 20 years.</p> <p><b>Material:</b> Thermally stabilized polypropylene.<br> <b>Operating temperature:</b> -40 °C / +130 °C (peaks up to +150 °C).<br> <b>Flammability:</b> Flame-retardant and self-extinguishing UL94-V2, FMVSS 302, DIN 75200.<br> <b>Features:</b> High flexibility, resistance to alcohols, grease, mineral oils and fuels. Suitable for photovoltaic systems, mechanical and automotive industries. Tensile strength 26 MPa, elastic modulus 1300 MPa, elongation at break >250%.<br> <b>Supply & packaging:</b> Unit of measure 1 meter, bulk supply without cuts, coils of 10, 25, 50 or 100 meters depending on reference, special lengths on request.</p>   <p>Our <b>MDB</b> branch sleeves are made of soft <b>TPE</b> in a “T” shape for creating branches between tube sections.</p> <p>These sleeves, <b>UV-resistant</b>, are pressure-mounted on tube ends and, thanks to their internal teeth, adhere perfectly to the tube's outer profile. Wall mounting holes have a diameter of Ø 4 mm. They can be used even between tubes of different sizes.</p> <p>· <b>Material:</b> TPE<br> · <b>Color:</b> black<br> · <b>Operating temperature:</b> -40 °C / +120 °C (with ends up to +150 °C)<br> · <b>IP protection:</b> IP66 according to EN 60529</p> <p><i>Available in grey on request.</i></p>   <p>Our coupling sleeves <b>MDA</b> are manufactured in flexible <b>TPE</b> for joining conduits.</p> <p>These <b>UV-resistant</b> components are press-fitted onto conduit ends. The internal serration ensures a secure grip by adapting to the external profile. They are used to extend conduit sections or to connect corrugated conduits with other types of tubing.</p> <p>· <b>Material:</b> TPE<br> · <b>Color:</b> black<br> · <b>Operating temperature:</b> -40°C / +120°C<br> · <b>IP protection:</b> IP66 according to EN 60529</p> <p><i>Free from cadmium, silicone and halogens. Grey color available on request.</i></p>
