Description and features
The ribbed threaded inserts LJ for square tubes are offered in different designs and sizes. The metric nut, which is incorporated during the injection process, offers a strong fixation. The combination of the available sizes and materials (LDPE and PA6) will offer different properties, such as resistance to weight (we recommend carrying out tests through a sample order).
RAL colors manufactured Product images and technical drawings
Product view
Technical drawing
Video
Part numbers and dimensions of Square threaded tube insert
| Reference | For Tube |
Tube Thickness |
Metric Thread |
h |
D |
H |
d / d1 |
L |
More Info. |
||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 00300400318 | 20 x 20 | 1,50 to 2,00 | M8 | 4,00 | 20,50 | 6,00 | 14,70 / 19,00 | 14,20 | |||||
| 00300400428 | 20 x 20 | 1,50 to 2,00 | M8 | 25,00 | 20,20 | 6,80 | 15,00 / 19,00 | 30,50 | |||||
| 00300400434 | 20 x 20 | 1,50 | M8 | 4,50 | 20,20 | 6,20 | 15,00 / 19,00 | 30,50 | |||||
| 00300400319 | 25 x 25 | 1,50 to 2,00 | M8 | 4,00 | 25,80 | 7,00 | 19,10 / 22,50 | 13,60 | |||||
| 00300400429 | 25 x 25 | 1,50 to 2,00 | M8 | 15,00 | 25,70 | 6,80 | 19,00 / 23,00 | 29,40 | |||||
| 00300400435 | 25 x 25 | 1,50 | M8 | 4,50 | 25,70 | 6,80 | 19,00 / 23,00 | 29,40 | |||||
| 00300400320 | 25 x 25 | 1,50 to 2,00 | M10 | 5,00 | 26,00 | 6,50 | 18,50 / 23,30 | 12,80 | |||||
| 00300400430 | 25 x 25 | 1,50 to 2,00 | M10 | 15,00 | 25,00 | 6,80 | 19,00 / 23,00 | 29,40 | |||||
| 00300400436 | 25 x 25 | 1,50 | M10 | 5,00 | 25,00 | 6,80 | 19,00 / 23,00 | 29,40 | |||||
| 00300400323 | 30 x 30 | 1,50 to 2,00 | M8 | 5,00 | 29,80 | 8,00 | 23,00 / 27,00 | 12,80 | |||||
| 00300400431 | 30 x 30 | 1,50 to 2,00 | M8 | 15,00 | 30,00 | 7,60 | 24,00 / 28,00 | 30,00 | |||||
| 00300400324 | 30 x 30 | 1,50 to 2,00 | M10 | 4,00 | 29,80 | 8,00 | 24,00 / 28,30 | 12,80 | |||||
| 00300400432 | 30 x 30 | 1,50 to 2,00 | M10 | 15,00 | 30,00 | 7,60 | 24,00 / 28,00 | 30,00 | |||||
| 00300400437 | 30 x 30 | 1,50 | M10 | 5,00 | 30,00 | 7,70 | 24,00 / 28,00 | 30,00 | |||||
| 00300410007 | 30 x 30 | 1,50 to 2,00 | M10 | 15,00 | 30,00 | 7,60 | 24,00 / 28,00 | 30,00 | |||||
| 00300400326 | 30 x 30 | 2,50 | M10 | 5,00 | 29,80 | 8,00 | 23,00 / 26,80 | 13,00 | |||||
| 00300400327 | 35 x 35 | 1,50 to 2,00 | M10 | 5,00 | 34,80 | 8,00 | 29,30 / 33,80 | 13,20 | |||||
| 00300400328 | 40 x 40 | 1,50 to 2,00 | M10 | 5,00 | 39,60 | 8,00 | 33,70 / 38,20 | 13,20 | |||||
| 00300401047 | 45 x 45 | 1,50 to 2,00 | M10 | 5,00 | 44,70 | 8,00 | 39,20 / 42,50 | 13,40 | |||||
| 02300400999 | 80 x 80 | 2,00 | M12 | 10,00 | 80,00 | 5,00 | 74,00 / 76,00 | 30,00 | |||||
| 02300401000 | 80 x 80 | 3,00 | M10 | 8,00 | 80,00 | 5,00 | 72,00 / 74,00 | 30,00 |
