This ratcheting action rivet features a rigid design which provides an outstanding bond created by the action of the interlocking gripper teeth. It garantees a rigid bond that will be difficult to separate. With the larger head diameters it makes binding of soft materials a simple application. For holding flat panels together, 2 parts are required, that would be snapped into each other. We suggest you to adjust the hole diameter to the rod of the part in order to garantee a resilient bond.

Drawing PDF:
UL94:   V2
IP:
RoHS:
Measures expressed in: Millimeters
Video:


Reference
Hole size
Panel thickness
B
A



More
Info.
01300100820 5,50 5,40 to 7,00 5,30 10,00
00100300357 6,35 5,97 to 7,54 5,55 9,53
00100300360 6,35 6,00 to 7,50 5,50 15,88
00100300359 6,35 8,80 to 12,70 8,75 9,55
00100300361 6,35 8,79 to 12,70 8,73 15,88
00100300583 6,35 12,70 to 20,62 12,70 9,53
00100300585 6,35 12,70 to 20,62 12,70 15,88
00100300584 6,35 19,81 to 34,93 19,05 9,53
00100300586 6,35 19,81 to 34,93 19,30 15,90
00100300350 7,14 5,97 to 7,54 5,50 10,31
00100300342 7,14 5,97 to 7,54 5,50 19,05
00100300344 7,14 8,79 to 12,70 8,70 19,10
00100300352 7,14 8,79 to 12,70 8,73 10,31
00100300354 7,14 12,70 to 20,62 12,70 10,31
00100300346 7,14 12,70 to 20,62 12,70 19,05
00100300356 7,14 19,81 to 34,93 19,05 10,31
00100300348 7,14 19,81 to 34,93 19,05 19,05
01300100821 7,60 9,80 to 12,80 8,30 19,00
01300100822 7,60 13,50 to 16,50 12,00 19,00
01300100823 9,50 36,00 to 49,00 35,70 19,00
00100300362 11,10 11,10 to 19,05 11,10 34,93
