Our hexagon shaped lock nut has been designed to fit a variety of thread sizes, and to execute a big range of applications and to be used together with a cable gland. Nylon nuts are durable, non-conductive and resistant to corrosion.

Drawing PDF:
UL94:   HB
IP:
RoHS:
Measures expressed in: Millimeters
Video:

PRTUE
PRTUE

Reference
Suitable for
A
B



More
Info.
01500800061 M12 5,50 17,00
01500800062 M16 5,50 22,00
01500800063 M20 5,80 24,00
01500800064 M25 7,00 32,00
01500800065 M32 7,00 41,00
01500800066 M40 7,00 50,00
01500800067 M50 8,50 60,00
01500800068 M63 8,00 75,00
01500800051 PG 7 5,00 19,00
01500800052 PG 9 5,50 22,00
01500800053 PG 11 6,00 24,00
01500800054 PG 13,5 6,00 27,00
01500800055 PG 16 6,50 30,00
01500800056 PG 21 7,00 36,00
01500800057 PG 29 7,50 46,00
01500800058 PG 36 8,00 60,00
01500800059 PG 42 8,00 65,00
01500800060 PG 48 8,00 70,00

If you are interested in our family PRTUE, you may be interested in these families as well:

This part is a 100% waterproof cable gland (IP68 - 5 bar). Its design gives the possibility to fit several cable diameters with secure protection and fastening. It can be supplied with a plug protector, and an O-ring PRP for watertightness and an adapter joint PRTI for several cables. Also, you can find the corresponding lock nut: PRTUE. Please contact us for more information.   PRPRF flexible cable glands, manufactured according to <b>DIN EN 62444/50262</b>, allow the cable to move freely even continuously and offer excellent protection even when vibrations are present. The body is made of <b>PA6</b> (nylon6) and the internal seal of <b>CR</b> (Rubber - Chloroprene). It complies with IP66 and IP698 (up to 5 bar) type 4X (UL 50E) protection. For optimal sealing, we recommend using the lock nut (families <a href=' https://www.iscsl.co.uk/hexagonal-lock-nut-with-flange/prtu/ ' target='_blank'><b>PRTU</b></a>, <a href=' https://www.iscsl.co.uk/hexagonal-lock-nut/prtum/ ' target='_blank'><b>PRTUM</b></a>, <a href=' https://www.iscsl.co.uk/hexagonal-lock-nut/prtue/ ' target='_blank'><b>PRTUE</b></a>) and the flat section O-ring (<a href=' https://www.iscsl.co.uk/o-ring-for-metric-and-pg-threads/prp/ ' target='_blank'><b>PRP</b></a>), which are sold separately.<br>All three colours are UV resistant (F1 according to UL 746C). Under special production, we can supply the colours RAL3020 (red), RAL9003 (white) and RAL5015 (blue), as well as replacement seals for multi-core or flat cables. <br><br>Standards and Certifications: VDE (EN 62444), UL (UL 514B, CSA C22.2 Nr. 18.3-12 and 94.2-15), c-CSA-us (CSA C22.2), DNV GL (EN 62444). <i>Some regulations may not cover all sizes, please consult our sales department</i>.   This o-ring is ideal to get a good and water-proof sealing in our cable glands PRPRE and our plugs PRTH and PRT. It can be used in the majority of industrial applications including water, oil, petrol and most chemicals. Our o-ring is available for metric thread and for PG thread.   Our hexagon shaped lock nut with round sealing flange has been designed to fit a variety of thread sizes, and to execute a big range of applications and to be used together with a cable gland. Nylon nuts are durable, non-conductive and resistant to corrosion.   Our hexagon shaped lock nut <b>manufactured in brass</b>, has been designed to fit a variety of thread sizes, and to execute a big range of applications and to be used together with a cable gland.
