Our straight connector has been designed for rectangular tubes. It is supplied with or without internal metal core.
 RAL colors manufactured

Drawing PDF:
UL94:
IP:
RoHS:
Measures expressed in: Millimeters


Reference
For Tube
Tube Thickness
L
H



More
Info.
02300400131 20 x 15 1,50 37,00 5,00
02300400129 25 x 20 1,50 37,00 5,00
02300400139 30 x 15 1,50 35,50 5,00
02300400002 30 x 20 1,50 37,00 5,00
02300400138 30 x 20 2,00 40,00 3,00
02300400136 40 x 20 1,50 36,00 5,00
02300400258 40 x 20 2,00 50,00 5,00
02300400134 50 x 20 2,00 40,00 5,00
02300400135 50 x 30 2,00 49,00 5,00
02300400132 60 x 40 1,50 48,00 5,00
02300400130 60 x 30 2,00 34,00 5,00
02300400137 60 x 20 2,00 40,00 5,00
02300400133 60 x 40 2,00 48,00 5,00

If you are interested in our family SAIAA, you may be interested in these families as well:

Our elbow connector has been designed in order to connect 2 rectangular tubes. This connector has a small rounded external part which gives a good finish.   Our connector for rectangular tubes has been designed with 2 cavities for hexagonal nuts. We can supply the part without nuts, or with a nut up, or one nut down, or with the 2 nuts. Please consult us.   Our elbow connector has been designed in order to connect 2 rectangular tubes.   Our standard ribbed insert for rectangular tubes is available in multiple sizes. It is also available for square tubes: LE, oval tubes: LFO, triangular tubes: LFD and octogonal tubes: SLJLO.
